PVC STEEL WIRE HOSE

Wire reinforced PVC Hose is suitable for a range of applications including delivery of food, water chemicals or other waste materials. Constructed from clear PVC with a high tensile steel helix and is water resistant, durable, smooth bore, good abrasion, rot and chemical resistance, good crush and kink resistance. Preferable for the suction and delivery of water, and dilute chemicals.

Suction and delivery hoses, otherwise simply known as S&D hoses or suction and discharge hoses, can not only transfer media from one location to another via gravity, but they also use negative pressure to act more like a vacuum without collapsing, crushing or kinking under the pressure. Manufactured from flexible PVC with a high-tensile carbon steel wire helix, this suction and delivery hose is suitable for transferring industrial liquids and food products.

CONTACT NOW down load to pdf

Details

Tags

PRODUCT DETAILS

Suction and delivery of water, and dilute chemicals are preferred.

The suction and delivery hose is made of flexible PVC with a high-tensile carbon steel wire helix for water, granules, foodstuffs, and diluted chemicals. Clear hose is ideal for applications that require quick and easy inspection. It is UV-compounded to withstand atmospheric conditions and maintain clarity.

A smooth bore allows for maximum flow, is non-toxic, and can be used in food applications. Contrary to popular belief, this suction and delivery hose is made of flexible PVC with a high-tensile carbon steel wire helix and is suitable for transferring industrial liquids.PVC Reinforced with Steel Wire Hose has a wire reinforcement built into the wall and a clear mirror-smooth surface for visual flow and material buildup—lightweight yet rigid, abrasion-resistant, kink and crush-resistant.

PVC steel wire-reinforced hoses are widely used in factories, agriculture, engineering, and sanitation to suction and discharge water, oil, and powder. In shipyards, industries, buildings, agricultural machinery, and industrial machinery.PVC Spring Hose, PVC Steel Suction Hose, Steel Spiral Reinforced Hose PVC Suction Hoses, water suction hoses with steel wire, PVC Suction Hoses PVC steel wire reinforced hose is widely used for suction and discharge of water, oil, and powder in the factory, agriculture, engineering, and sanitation lines. In shipyards, industries, buildings, agricultural, and industrial machinery.

PRODUCT DISPLAY

Construction:
Tube and cover:transparent pvc
Reinforcement:steel wire spiral

Read More About pvc steel wire reinforced hose

Application:
Widely used in water supply & draining for equipment under normal pressure condition in factory equipment farm irrigation, Pneumatic machine air hose, high pressure cleaning equipment, engine parts, heavy machine and construction site, etc.

Read More About pvc hose with steel wire

Characteristics:

●Light weight, flexible, elastic,
●portable and excellent adaptability;
●Acid-proof, alkali-proof,
●anti-UV, long service time
●Can be made food grade
●Can be high temperature resistant and anti-static

Temperature:-29℃ (-20 ℉ ) to 80℃(+176 ℉)

SPECIFICATION STANDARD DUTY

size	ID	OD	Working Pressure	Bruse Pressure	Weight	Length	Volume
size	mm	mm	Bar	Bar	g/m	m/roll	m³/roll
1/2''	12	18	8	24	210	100	0.045
5/8''	15	21	6	18	260	100	0.075
3/4''	19	25	6	18	320	50	0.050
1''	25	31	6	18	450	50	0.068
1-1/4''	32	39	6	18	600	50	0.149
1-1/2''	38	45	6	18	700	50	0.182
2''	50	58	5	15	1200	50	0.292
2-1/2''	64	73	5	15	1500	30	0.3
3''	76	86	4	12	2000	30	0.385
4''	102	112	4	12	3000	30	0.648
