Pneumatic Tubing Flexible PU Pneumatic Tube Air Hose for Air Compressor Fitting

PU pneumatic hoses are mostly used in air pipes, water pipes and material conveying pipes, especially for conveying water and other liquids. Excellent performance of resistance against.High pressure, vibration, corrosion, attrition and bending of PU air hoes. Widely used in automobile industry, construction industry, industrial robots and pneumatic tools. Considering the comprehensive material, its service temperature is: -40ºC(-104ºF) to +121ºC(+250ºF).

CONTACT NOW down load to pdf

Details

Tags

Characteristic:
Excellent flexibility, bending radius is small
Non-toxic, smooth
Hardness is constant, service life is long.
Excellent performance of resistance against high pressure, vibration, corrosion, attrition and bending of PU air hose.

Application:
Delivery hose usage
Automobile industry
Construction industry
Industry robots and pneumatic tools.
Transport water and other liquid.
Hydraulic machinery
Electronics industry

Temperature: -40ºC(-104ºF) to +121ºC(+250ºF)

I. D	O. D.	Length	Working pressure	Burst pressure	Bending Radius	Weight
	mm	mm	m	bar	bar	mm	kg/roll
Metric system	2	3	200	10	35	8	1.4
	2.5	4	200	10	32	10	2.32
	3	5	200	10	32	8	3.56
	4	6	200	8	24	15	4.32
	5	8	100	10	35	20	4.2
	5.5	8	100	8	30	20	4.75
	6	8	100	6	20	25	5.4
	6.5	10	100	8	26	25	6
	8	12	100	8	28	30	8.2
	9	12	100	6	18	40	8.8
	10	14	100	8	24	45	9.4
	12	16	100	8	24	65	11.32
	13	16	100	6	18	75	8.9

	I. D	O. D.	Length	Working pressure	Burst pressure	Bending Radius	Weight
	mm	mm	m	bar	bar	mm	kg/roll
British system	2	3.2	200	10	32	8	1.6
	2.5	4	200	10	32	10	2.3
	4.6	6.4	200	8	24	15	4.2
	5	8	100	10	32	20	4.2
	6.5	9.6	100	8	24	25	5.1
	9.6	12.6	100	8	24	35	6.7
